Flexible Solar Panel 80W 12v

Manufacturers Part Number: STPVF080
Flexible Solar Panel 80W 12v
Flexible Solar Panel 80W 12v

Flexible Solar Panel 80W 12v Image (1)


Our Price:
£229.96 Inc VAT
£191.63 Ex VAT
Order Code: ZSOLSTPVF080
Manufacturer: PV Logic
RRP: £280.00 Inc VAT
Ready to ship in 5 - 7 Working days

Delivery Options
Choose Destination
Postcode/ZIP:

Standard Service
Transit Time 1 - 2 Working Days.
(inc TAX)
FREE





Flexible Solar Panel 80W 12v

From the 10wp to the 80wp, PV Logic Flexi is well suited for use where a super robust, low profile and lightweight panel is needed, or the substrate to which the panel will be fixed has a slight curve. Ideal for marine buoys, boat decks, camper vans etc.

Contents

  • 1 x STPVF080 – 80wp solar panel
  • 1 x 4m Cable (attached)
  • 1 x Fuse
  • 6 x Ring Terminals
  • 1 x Instruction Sheet

Specifications
Power (Wp)     80watts
Nominal Voltage (Vmp)      18V DC
Nominal Current (Imp)     4.45A
Open Circuit Voltage (Voc)     21.6V
Short Circuit Current (Isc)     4.82A
Operating Temperature     -40 to + 80 Deg C
Max System Voltage     750V DC
Dimensions     885x665x3mm (Junction box 10mm)
Weight     4Kg
Approx. watt-hours/day**     480W
Approx. amp-hours/day**       26.7A

** Based on 6 hours of average daily peak sunlight hours

Self-healing top surface
The ETFE top layer gives the PV Logic Flexi extra resilience in really tough conditions. ETFE has a memory effect or self-healing capacity in the event the panel comes into contact with branches etc, thus ensuring any slight abrasions are ‘healed’ within a few hours. The Flexi range can even be walked on with soft deck shoes! During production the ETFE is dimpled to further protect the panel and provide an anti-slip surface, particularly useful if the panel is fitted to a boat deck.

Completely waterproof
Each panel is assembled to ensure complete encapsulation. This ensures the 6 layer heavy duty laminate protects the solar cell circuit from extreme conditions. The junction box is also injected with special silicon, guaranteeing no water ingress.

Cells protected from hot spots.
Where used on a camper van or boat, partial shading of a solar panel is typical. In these circumstances, heat build-up and damaging hot spots can occur leading to a significantly reduced life cycle of the panel. The larger 60w and 80w PV Logic Flexi panels have up to two shading diodes housed within the fully waterproof junction box to prevent this occurrence.

Superior design
There are no square edges on a PV Logic Flexi! Rounded panel corners and a unique curved junction box provide superior adhesion, no snag lamination and no sharp edges. The junction box is mechanically fixed in addition to being bonded to the panel. Strain relief is provided for the fitted 4m UV stabilised PV cable ensuring it cannot be accidentally pulled from the junction box.

Easy fix
The Flexi range can be bonded to flat or slight curved surfaces (3cm curve per metre) such as painted aluminium, metal, GRP and fibreglass using Simson ISR 70-03.

Warranty
The Flexi range is setting new standards with a 5 year product and a 20 year performance warranty*  .


Please note.
All of our semi flexible panels will only bend from the top (has the cable and logos) to the bottom a maximum of 10% of panel length.
Bending the panel greater than this or trying to bend the panel from left to right will possibly damage the panel and also invalidate your warranty.
